| | DisplayDrawer (EPD_Display *display) |
| |
| void | SetDesign (uint8_t design) |
| | Setting up the design. More...
|
| |
| void | DrawConnect () |
| | Design and item layout for the Connecting screen. More...
|
| |
| void | DrawAP () |
| | Design and item layout for the Wireless network initialization screen. More...
|
| |
| void | DrawCard (DisplayContent_t *data) |
| | Design and item layout for the Nameplate (card) mode. More...
|
| |
| void | DrawTable (DisplayContent_t *data, int hour, String date, String day) |
| | Design and item layout for the Timetable mode. More...
|
| |
| void | DrawMeeting (DisplayContent_t *data, int hour, String date, String day) |
| | Design and item layout for the Timetable mode. More...
|
| |
| void | Show () |
| | Shows the content - Sends the image buffer in RAM to e-Paper and displays. More...
|
| |
| void | SetRotate (uint16_t rotate) |
| | Rotate image by 0,90,180,270 degrees. More...
|
| |
| void | SetMirroring (uint8_t mirror) |
| | Select Image mirror. More...
|
| |
| void | SetScale (uint8_t scale) |
| | Set display scale. More...
|
| |
| void | SetPixel (uint16_t Xpoint, uint16_t Ypoint, uint16_t Color) |
| | Draw Pixels. More...
|
| |
| void | Clear (uint16_t color) |
| | Clear the color of the picture. More...
|
| |
| void | ClearWindows (uint16_t Xstart, uint16_t Ystart, uint16_t Xend, uint16_t Yend, uint16_t Color) |
| | Clear the color of a window. More...
|
| |
| void | DrawPoint (uint16_t Xpoint, uint16_t Ypoint, uint16_t Color, DOT_PIXEL Dot_Pixel, DOT_STYLE Dot_Style) |
| | Draw Point(Xpoint, Ypoint) Fill the color. More...
|
| |
| void | DrawLine (uint16_t Xstart, uint16_t Ystart, uint16_t Xend, uint16_t Yend, uint16_t Color, DOT_PIXEL Line_width, LINE_STYLE Line_Style) |
| | Draw a line of arbitrary slope. More...
|
| |
| void | DrawRectangle (uint16_t Xstart, uint16_t Ystart, uint16_t Xend, uint16_t Yend, uint16_t Color, DOT_PIXEL Line_width, DRAW_FILL Draw_Fill) |
| | Draw a rectangle. More...
|
| |
| void | DrawCircle (uint16_t X_Center, uint16_t Y_Center, uint16_t Radius, uint16_t Color, DOT_PIXEL Line_width, DRAW_FILL Draw_Fill) |
| | Use the 8-point method to draw a circle of the specified size at the specified position. More...
|
| |
| void | DrawChar (uint16_t Xpoint, uint16_t Ypoint, const char Acsii_Char, sFONT *Font, uint16_t Color_Foreground, uint16_t Color_Background) |
| | Show English characters. More...
|
| |
| void | DrawString_EN (uint16_t Xstart, uint16_t Ystart, const char *pString, sFONT *Font, uint16_t Color_Foreground, uint16_t Color_Background) |
| | Show English characters. More...
|
| |
| void | DrawNum (uint16_t Xpoint, uint16_t Ypoint, int32_t Nummber, sFONT *Font, uint16_t Color_Foreground, uint16_t Color_Background) |
| | Display nummber. More...
|
| |
| void | DrawTime (uint16_t Xstart, uint16_t Ystart, PAINT_TIME *pTime, sFONT *Font, uint16_t Color_Foreground, uint16_t Color_Background) |
| | Display time. More...
|
| |
| void | DrawBitMap (const unsigned char *image_buffer) |
| | Display monochrome bitmap - Use a computer to convert the image into a corresponding array, and then embed the array directly into Imagedata.cpp as a .c file. More...
|
| |
| void | DrawImage (const unsigned char *image_buffer, uint16_t xStart, uint16_t yStart, uint16_t W_Image, uint16_t H_Image) |
| | Display image. More...
|
| |
| | DisplayCanvas (DisplaySize_t s) |
| | Allocate the needed memory. More...
|
| |
| | DisplayCanvas () |
| |
| void | SelectImage (uint8_t index) |
| | Select Image. More...
|
| |
| void | NewImage (uint8_t index, uint16_t color) |
| | Create new image. More...
|
| |
Drawing the choosen display modes.
Public Member Functions inherited from DisplayCanvas
